Name that nut

RatLabGuy

RatLabGuy

You look like a monkey and smell like one too
Joined
May 18, 2005
Location
Churchville, MD
What is the name of this kind of nut...

It has a flange on the bottom (flange nut), but also an extra vertical "ring" around the top that is often pinched with a stake to crimp onto a stud that has a small matching chunk out of the top of it.

For example, on most FWD cars, inside the hub there is such a nut on the end of the CV axle, to get the CV out you have to un-stake then unscrew. IIRC also found on pinions and output flanges. In this case it's on both ends of the cross-bar in IFS Toy upper control arms.

I need two in an m18x1.5 (27mm). I always call it a "stake nut" but failing w/ finding a source.

Nice - and will work in a pinch - but these have a flange on the bottom like a normal flange nut. Necessary in this case b/c they have to hold down a giant washer.
And still - what's it called, so I can source one locally?

Wow. Did a little searching. I can't find anything like that in that size. Fastenal seems to jump from 16 to 20mm. I'd go into a local store and see if they'll get the book out for you and start flipping.

Call Toyota?????

snappy said:
Call Toyota?????
Click to expand...

I may try that... howver my experience has been that w/o either a part number, or a specific part name (neither of which are identified in the FSM) thet have no clue what you are talking about or find the part...

Im SASing a 90 runner. Want my IFS stuff?

RHSCTJ said:
Im SASing a 90 runner. Want my IFS stuff?
Click to expand...

Sure. Spares always good to have on hand.
Hell right now I just need those nuts lol.
