Purple YJ Build

Discussion in 'Build Threads' started by Van-go, Jan 15, 2018.

  1. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    Progress

    DABEBB6C-5C67-45CE-9D40-50BCA3A1B759.jpeg D9CA2FD9-7607-4082-A918-7621468149F6.jpeg

    drkelly and doc like this.
  2. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    Chop chop.


  3. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    Picked up some 37’s from a member.
    I still want 40’s but with 4.56 gears installed in the rear already I better not.

    4CFFDF85-C47F-4105-BC2C-2159473DA2D4.jpeg 4B6B06D4-A101-4D8C-99F1-B71B2F7D1C9D.jpeg C638CFBE-0EB0-4581-89E1-2F6162C8DD4E.jpeg

    Got everything cut off of the passenger side.
    Shoutout to Milwaukee tools for a killer sawzall. Only used one blade for this too. And I cut a 6 inch 3/8 I beam that I jacked my floors with in my basement. Killer blades.

    Grinding is always fun. Just not this kind.

    Do I need to plate the side of the frame for leaf springs?

    22B1666C-FED3-4A06-94EB-A6A344E7380D.jpeg 2E63C43A-E42B-4E0A-A57E-04406C082688.jpeg

    Drivers side is next.


    Last edited: Jul 7, 2019
    BigSouth and jeepcj3a like this.
  4. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    Made a little progress this weekend. Lots of metal shavings to clean up.
    Pretty much ready to get the front leaf mounts and slider boxes mocked up.

    2588A420-E618-47C4-9F63-AF0059899599.jpeg 901844C8-8861-4EA8-ABE8-63C5DD6C846C.jpeg C53D2CCB-79D6-419C-B42F-09AFED9162CB.jpeg A71B5F8F-68A8-440E-BA15-D1B134222E86.jpeg

    BigSouth likes this.
  5. BigSouth

    BigSouth Doesn't play well with others!

    Joined:
    Jun 8, 2011
    Location:
    Shelby, NC
    YES, definitely! Stock frame rails like to tear with the stress of real wheeling. With it being Toyota, you can probably find a kit for the rear. Plasma cut out your own for the front.

  6. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    That’s what I was thinking. The rear frame is a joke. It’s thin “C” channel from cab back. I just know I’m going to end up selling this thing as I need more $ to finish the buggy. So trying to do everything for as cheap as possible.

  7. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    Also,
    If I run flat plate across the front, won’t that make a place to trap water? Unless I cut the plate around each hole already in the frame and weld around it.


  8. Chris_Keziah

    Chris_Keziah Joe Dirt

    Joined:
    Dec 1, 2010
    Location:
    Winston-Salem
    Cover the holes, water should drain down to the lower section and out other holes. Only thing you need to leave un-covered is the vin stamped on the frame.

  9. BigSouth

    BigSouth Doesn't play well with others!

    Joined:
    Jun 8, 2011
    Location:
    Shelby, NC
    To keep weight down and make it stronger, I’d do it fish plate style. Multiple holes to weld more. Trapping water wouldn’t be a concern of mine. An 1/8th inch hole on the bottom of the rail would drain.

    Chris_Keziah likes this.
  10. drkelly

    drkelly Dipstick who put two vehicles on jack stands

    Joined:
    Mar 21, 2005
    Location:
    Oak Ridge/Stokesdale, NC
    I would not bother plating the frame.

  11. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    If I was trying to weld a coil over mount on I would 100% do it, but if not I really don’t think it needs it for leafs.

  12. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    Trying to figure out how far forward or back I need the axle to be. Also, don’t know if the front crossmember hangs too low.

    I just kinda tacked it up so I think it needs to move back a couple inches.

    Trying to get it just where it needs to be for minimal fender trimming.

    The only difficult clearance issues I foresee is the front driveshaft and exhaust.

    7C86F6EA-2237-4AAB-BFE3-41933020F74B.jpeg 366AF6B6-2595-4DDF-846F-167D1AEBD5B6.jpeg 8A7EB507-861B-4420-8AC1-E4D22E40E386.jpeg

    doc, untchabl, drkelly and 1 other person like this.
  13. paradisePWoffrd

    paradisePWoffrd Recovering Project Junkie

    Joined:
    Nov 5, 2005
    Location:
    Newton, NC
    Can you just extend the tubing out the sides of the existing frame rail vs being underneath? or french that crossmember up into the frame? I think that would be the cleanest looking and hang down the least.

  14. Chris_Keziah

    Chris_Keziah Joe Dirt

    Joined:
    Dec 1, 2010
    Location:
    Winston-Salem
    I bet it would make getting steering packaged a bitch if he moved the crossmember up.

    @Van-go I'm not sure what tire size you plan to run but I would try and move the axle far enough forward to leave a 1-2" of clearance at the firewall.

  15. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    Should I go ahead and assemble the axle and put tires on to check clearances before I mount the springs etc?
    I am gonna run37’s, but I want to be able to run 40’s if I can.

    doc likes this.
  16. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    This one is for sale on FB. Been looking at it for ideas.
    C7F93E40-62AB-493F-93B8-8CE20525A90A.jpeg A80B72D6-BE26-49F7-B34E-8EB92264988F.jpeg 2A0A5CEC-D9DD-426E-8AC8-D82E4927BB92.jpeg 8C670E7D-B385-4AC2-8CB4-F47F8B25EFC3.jpeg

    doc, obullfish and drkelly like this.
  17. Chris_Keziah

    Chris_Keziah Joe Dirt

    Joined:
    Dec 1, 2010
    Location:
    Winston-Salem
    I would.

  18. Brownsxj

    Brownsxj Well-Known Member

    Joined:
    Mar 19, 2008
    Location:
    Durham NC
    We had a friend in college that had a 04 Tacoma on leafs with a SAS. The driver side frame started twisting as he turned the wheel back and forth. I would recommend plating that side at least.

    StretchASU and Van-go like this.
  19. DannyH

    DannyH smokey burnouts

    Joined:
    Jan 10, 2014
    Location:
    Albemarle, North Carolina
    I would make sure you can squeeze a 40” tire in there without chopping too far back (into the door).

    Also have been eyeing that taco on FB. It’s a neat rig.

    Great work keep it up!

  20. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    Moved the front cross member back 2 inches.

    I think this is where the axle will end up.

    Hopefully the YJ leafs sit pretty flat. Otherwise I’ll have to lower the front spring hanger down to get the height I want.

    Hoping to have it on its own weight this weekend.

    30122020-150E-45CF-BA6A-4C6F3D45A575.jpeg 9C1C5E44-9738-4628-9F0E-A945C050C273.jpeg 88F887A6-F202-44A4-BE7A-BBDFE0ADB9FE.jpeg BC1DA9A7-74F8-4FC6-981E-34410E06E4E5.jpeg EF92D24E-1423-40C0-8C16-A82914841246.jpeg D8D1F3B4-A5F4-4041-AD93-73112552BE8E.jpeg

    Going to run spacers up front so the tires don’t rub the leaf springs.

    96E5FA9F-2AA2-416B-8B81-770B1E02F974.jpeg D7B30990-4A70-4199-83C4-DA9E03483EE7.jpeg 6ABB6813-EFE0-4029-814E-AE8A740342FF.jpeg

  21. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    So I decided that I didn’t like the YJ leafs cause the slider boxes were too far forward and would hit the tires at full lock.

    3FF82616-2A96-4153-8649-4319716CE381.jpeg BF0B7DDF-B0AE-43AA-8BC1-096BC920EAB7.jpeg

    I had some rear Tacoma springs laying around I bought off here a few years back from @drkelly I think??

    Got those installed which moved the slider boxes way back almost to the trans cross member. Looks way cleaner.


    Had to push the front cross member forward too, which I’m not thrilled about, but it is what it is.
    It’s on its own weight now. Needs some more leafs to sit level, but it’s all good.
    FE60A10B-6A9A-44EB-849D-DC72DEC7750D.jpeg E51EBC4C-C95C-4CA1-8096-10B87959800B.jpeg 3FED4BD8-414D-4159-886B-8B4C0B12CE93.jpeg

  22. Van-go

    Van-go Not an old man

    Joined:
    Dec 11, 2014
    Location:
    Greensboro
    Didn’t like the cross member.
    Ditched it. Just going to mount the spring hangers higher and play with the springs to make up for the lost height with more arch.

    Should also help the caster angle out.

    EA3B598B-4754-4ECB-992C-48CEF25102BD.jpeg 99EF806D-C5D0-4C52-A44F-2032B83F6579.jpeg
